  • Stock: In Stock
  • Model: EVGA
4,800EGP

Here are the detailed specifications of the EVGA 850 B5, 80 Plus BRONZE 850W, Fully Modular, EVGA ECO Mode, 5 Year Warranty, Compact 150mm Size, Power Supply 220-B5-0850-V1:

General

  • Brand: EVGA
  • Series: B5
  • Model: 220-B5-0850-V1
  • Type: ATX12V / EPS12V

Details

  • 80 PLUS Bronze certified, with 85% efficiency or higher under typical loads
  • Fully Modular to reduce clutter and improve airflow
  • EVGA ECO Intelligent Thermal Control System eliminates fan noise at low to medium loads
  • Single 135mm Fluid Dynamic Bearing fan with semi-passive operation
  • Active PFC (Power Factor Correction)
  • Over Voltage Protection (OVP), Over Current Protection (OCP), Over Power Protection (OPP), Short Circuit Protection (SCP), Under Voltage Protection (UVP), and Inrush Current Protection (ICP)
  • 5 Year Warranty and unparalleled EVGA Customer Support

Input

  • Input Voltage: 100-240VAC
  • Input Current: 10A / 5A
  • Input Frequency: 47Hz-63Hz

Output

  • +3.3V: 24A
  • +5V: 24A
  • +12V: 70.8A
  • -12V: 0.5A
  • +5Vsb: 3A

Connectors

  • 1 x 24-pin ATX (20+4)
  • 2 x 8-pin EPS (4+4)
  • 6 x 8-pin PCIe (6+2)
  • 9 x SATA
  • 3 x 4-pin Peripheral
  • 1 x Floppy

Dimensions & Weight

  • Dimensions: 150 x 50 x 86 mm (5.91 x 1.97 x 3.39 in)
  • Weight: 1.24 kg (2.74 lbs)

Additional Information

  • MTBF: >100,000 Hours
  • Approvals: TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS, Compliance with ErP Lot 3 2014 Requirement

Warranty

  • 5 Year Warranty
